Exploring the Architecture of the ABAP RESTful Application Programming Model
In this blog post, we’ll go into detail about the main architecture-relevant concepts of the ABAP RESTful application programming model.
This includes the technical components in which a RAP application is embedded at runtime.
Transaction Model
The RAP transaction model distinguishes between two phases in the processing of operations on business objects:
- During the interaction phase, operations are performed on a business object instance (e.g., a position is created or changed). As a result of these operations, instances of the respective CDS entities are stored in the transaction buffer.
- The subsequent save sequence is triggered by a commit. The state of the transaction buffer is persistently written to the database. The state of the transaction buffer isn’t kept across multiple requests, as this would violate a key REST principle. The CDS entity instances that are stored in the transaction buffer, which have been created, modified, or deleted (modify), can be considered a logical unit of work (LUW) within the SAP system. As part of the save sequence, the LUW is persistently written to the database within a database LUW.
The draft handling in the ABAP RESTful application programming model allows to temporarily store the state of the transaction buffer with inconsistent application data persistently on the database. This enables you to distribute the interaction phase across multiple standalone requests or user sessions without violating the REST principles of stateless communication. Users can continue their work at a later point in time, regardless of the terminal device. The draft handling functionality is fully implemented by the RAP runtime.
Basically, the ABAP RESTful application programming model doesn’t preclude the implementation of a stateful application. The RAP transaction model technically includes an area (the transaction buffer) where the application state can be stored on the server side. However, in this book we’ll focus on REST-based applications.
Implementation Types
The ABAP RESTful application programming model includes the concept of the implementation type, which you use to specify who provides the implementation of reading functionality (query) and transactional or writing functionality (behavior). There are two implementation types: managed and unmanaged. In the managed case, the programming model provides the desired functionality; in the unmanaged case, the application must do this by itself.
The technical implementation of read and write access or the behavior of a business object is handled by the business object provider. When implementing the business object, we distinguish between the use of the managed scenario and the unmanaged scenario:
Managed Scenario
In the managed scenario, you use a ready-made implementation of the business object provided by the ABAP RESTful application programming model, the managed business object provider. It implements the standard CRUD operations for creating (create), reading (read), updating (update), and deleting (delete) instances of the respective CDS entity during the interaction phase and the save sequence. This is also accompanied by the handling of the transaction buffer.
When using the managed scenario, an already executable business object that supports CRUD operations is available to you without any programming effort on your part. Optionally, you can add more logic to the save sequence (additional save) or implement it yourself (unmanaged save).
Unmanaged Scenario
In the unmanaged scenario, you can implement the standard functionality of a business object by yourself. This involves the interaction phase with the transaction buffer and the save sequence. This gives you the option of integrating the API of an existing application and wrapping it with RAP resources. This scenario is therefore often used for brownfield development.
In addition to the use cases that can be implemented by these implementation types, there are always very specific business requirements (e.g., the validation of a certain data constellation or the calculation of certain values of a business object instance). In these cases, the business object provider can’t provide an implementation. However, in both the managed and unmanaged scenarios, you can implement the respective business logic yourself.
Read accesses are referred to as queries in the ABAP RESTful application programming model. They can be implemented without transactional behavior or associated write accesses. A managed implementation of this type of read access is called a managed query, and an unmanaged implementation is called an unmanaged query. Via the managed query, the programming model provides the standard functions for reading business data from the underlying database. This also includes, for example, functions for sorting, filtering, or aggregating the read data. If you implement an unmanaged query, you can implement these functions yourself and thus have the option of including any data source in the programming model (e.g., via remote call of APIs), or bridging differences between the data model of the data source and that of the business object in the ABAP RESTful application programming model.
Entity Manipulation Language
The entity manipulation language (EML) is a standardized, type-safe API used to access the data and functionality of a business object. It’s an integral part of the ABAP language scope. Using EML, you can access instances of a business object in write mode (via the ABAP statement MODIFY ENTITIES), but you can also read individual instances from the transaction buffer (via READ ENTITIES).
EML plays a major role within the ABAP RESTful application programming Use cases model in the following use cases:
- Implementing the behavior of a business object: You can use EML statements to implement the behavior of a business object in ABAP. In this case, your application assumes the role of a business object provider.
- Performing operations on a business object: You need EML statements if you program an ABAP application that accesses the functionality of a business object as a consumer (i.e., assumes the role of the business object consumer). It’s also possible to use EML in the context of unit tests to check the functionality of a business object in your application.
When you use EML within the business object provider, for example, to read data for validation, you also use the EML in the business object consumer role. You use it to read data about the business object from the transaction buffer to validate it, bypassing authorization checks, for example, because the access is IN LOCAL MODE. You thus consume the read or write functionality of your own business object. In addition to read and write operations, you can also use EML to define transaction boundaries (COMMIT and ROLLBACK behavior) and trigger the save sequence.
Technical Context of Applications and Runtime Environment
In the figure below you can see the technical context in which an application created with the ABAP RESTful application programming model is embedded. Here, you will gain an idea of the technical paths and protocols that can be used to access the data and services of a RAP application. A RAP application uses the SAP HANA database to persist application data. CDS custom entities allow you to connect an external system or other data source through synchronous communication using a query programmed, specifically in ABAP.
